The Electrode Baking Oven is designed for high-temperature baking of welding electrodes to restore and maintain dryness.
It operates up to 400–450 °C, controlled through digital or analog settings. The oven offers strong insulation, uniform heating, and easy loading. Widely used in fabrication industries, shipbuilding, and heavy engineering for critical welding jobs.
| Application | Remove moisture from welding electrodes before use. |
| Capacity | 300 Kgs |
| Temperature Range | Ambient to – 3000C / 4000C / 5000C. |
| Temperature Controller | Digital |
| Trays | 20 Nos. |
| Power Supply | 415 Volts AC 3 Phase 50 Hz |
| Outer Finish | Enamel Paint |
| Inner Paint | Aluminium coating high temp. |
| Weight of equipment | 500-550 Kgs approx |
| Advantages | Can use for baking and holding both. |
